品牌:广和通
尺寸:32x29x2.4mm
频段:900/1800MHz
起订:1个
供应:999999个
发货:3天内
发送询价
Product Feature
• LTE FDD: Band 1/3/5/8
• LTE TDD: Band 38/39/40/41
• WCDMA: Band 1/8
• TD-SCDMA: Band 34/39
• GSM/GPRS/EDGE: 900/1800MHz
• LCC 32x29x2.4mm
• Operating temperature： -40℃~+85℃
• Storage Temperature: -45℃~+90℃
• Operating Voltage: 3.3V~4.4V
• AT Command Set: 3GPP TS 27.007 and
27.005, proprietary FIBOCOM AT commands
• TX Power
GSM900: 32.5 dBm±1dB
DCS1800: 29.5dBm±1dB
WCDMA : 23.5dBm±1dB
TD-SCDMA: 23.5dBm±1dB
LTE FDD: 23.0dBm±1dB
LTE TDD: 23.0dBm±1dB
Data
• LTE FDD: 150Mbps DL/50Mbps UL
• LTE TDD: 120Mbps DL/30Mbps UL
• UMTS: 384 kbps DL/384 kbps UL
• HSPA/HSPA+: 21Mbps DL/5.76Mbps UL
• TD-SCDMA: 4.2Mbps DL/2.2Mbps UL
• EDGE: 236.8Kbps DL/236.8Kbps UL
• GPRS: 85.6Kbps DL/85.6Kbps UL
